XBD-DL Low Speed Vertical Multistage Fire Pump

Item No.: XBD-DL
XBD-DL fire pump is mainly used for water supply pressurizing in fire-fighting systems. Also, it is suitable for water supply and drainage in cities, high buildings, long distance water delivery, heat transfer, bath room and hot-cold water cycle pressuriz
Description
Description
Description:
XBD-DL fire pump is a vertical, single suction, multistage centrifugal pump, used to deliver non-particles clean water and fluids similar with water in physical and chemical properties. It is mainly used for water supply pressurizing in fire-fighting systems and water drainage in factories and mines.

Technical Parameters:
Flow Rate Q:2~380m³/h
Head H:5~230m
Speed N:1450r/min
Caliber: Φ40~Φ200
Temp Range T: -15~+95℃
Service Pressure P: Max 2.5Mpa

Flow range: 5~80L/s
Pressure range: 0.2~2.25MPa
Motor power range: 1.5~200kW
Inlet/outlet diameter: DN50~DN200mm

Model Meaning
XBD5.7/2.5-100DL

XB: Engineering-oriented Application
D: Electric-driven Engine
5.7: Pressure (MPa)
25: Flow (L/s)
100: Inlet Diameter (mm)
DL: Vertical Multistage

Applications:
   XBD-DL fire pump is mainly used for water supply pressurizing in fire-fighting systems. Also, it is suitable for water supply and drainage in cities, high buildings, long distance water delivery, heat transfer, bath room and hot-cold water cycle pressurizing system in boilers.
