SP 60hz electric submersible deep well pump
Operating conditions
◆ Maximum water temperature:+35℃
◆ Maximum sand content: 0.25%
◆ Maximum immersion: 80m
Applications
◆ Water supply from wells or reservoirs;
◆ Living water supply;
◆ Industrial production;
◆ Fire fighting system;
◆ Garden use and agriculture irrigation.
Motor and Pump
◆ Rewindable motor or Full canned motor pump
◆ Three-phase: 110V ~ 580V 50hz / 60hz
◆ Single-phase: 110V ~ 220V 50hz / 60hz
◆ Equip with start control box or digital auto-control box.
◆ Pumps curve tolerance according to ISO 9906.
| Pumped medium | Clean water/Raw water |
| Flow range | 1.8~80m3/h |
| Lift range | 15~350m |
| Electric frequency | 50/60Hz |
| Outlet diameter | 1~4 inch |
| Speed | 2850~3500rpm |
| Motor power | 0.18~90KW |
| Motor voltage | 110~580V |
